Magneto PCP®

Intelligent System for Electro Submersible Pumps - PCP with Surface Permanent Magnet Motor (PMM)

The MAGNETO PCP® System is a combination of two technologies: a progressive cavity pump and a MAGNETO DH® Permanent Magnet Motor Drive Head, creating a hybrid solution that maximizes oil well productivity. On the surface it has an intelligent CILA2S® MAGNETO controller for oil production, either in the single CILA2S® configuration or in the multiple configurations of the advanced Well pad Optimization System (WOS®). This system features reduced power consumption due to the use of PMM motors, improving the performance of the entire system in the face of adverse well conditions.

MAGNETO PCP® Benefits:
  1. Complete PCP solution, fully integrated downhole and surface.
  2. Low energy consumption and higher system efficiency thanks to the use of PMM motors.
  3. Exclusive closed-loop control (F.O.C.® - Flux Oriented Control), which increases oil well profitability, energy savings and power factor.
  4. Integrated downhole sensor with intelligent event recorder.
  5. High performance in flowback detection for controlled restart.
  6. Physical pressure sensor backup with virtual pressure sensor.
  7. Better performance against viscous and unstable flows and high content of solid impurities.
  8. Lower specific heat release per unit of power due to the use of PMM.
  9. Ease of monitoring and adjustment of the main operating variables necessary to control well performance thanks to the applications installed in the Controller.
  10. Applications installed in the Intelligent Controller for Artificial Lift Systems (CILA2S®).
  11. Applicability in horizontal and deviated wells.
  12. Applications for different casing diameters.
  13. High abrasion resistance.
  14. 24 months warranty.
Magneto PCP Magneto DH
